Belimo Open/Close Damper Actuator, NM230A-S, IP54, 100-240VAC, 10Nm
SV Code: 683229382857Model No.: NM230A-S
100-240 VAC50/60Hz85-265 VAC35 dB(A)10 Nm
AED 665.00/ Piece
In stock — ships today
On our shelf and ready to go out today.
Return or exchange within 30 days of delivery.Sign in to see your account price and place orders.
Key features
- Power consumption (running): 2.5W
- Power consumption (holding): 0.6W
- Power Consumption For Wire Sizing: 5.5VA
- Connection Supply Control: Cable 1 m, 3x 0.75 sq.mm
- Connection Auxilary Switch: Cable 1 m, 3x 0.75 sq.mm
- Manual override: With push-button, can be locked
Fast delivery Genuine & warranty Bulk quotes
Specifications
| SV Code | 683229382857 |
| Brand | Belimo |
| Category | Damper Actuators |
| Unit | Piece |
| Voltage | 100-240 VAC |
| Frequency | 50/60Hz |
| Nominal Voltage | 85-265 VAC |
| Sound Power Level | 35 dB(A) |
| Torque | 10 Nm |
| Colour | Orange and Grey |
| Operating Temp | -30 to 50 Deg.C |
| Storage Temperature | -40 to 80 Deg.C |
| Control Type | Open/Close, 3 Point |
| Run Time | 150 Sec For 90 Deg Rotation |
| Switch Type | Single Pole Double Throw |
| Pollution Degree | 3 |
| Rotation Angle | 95 Degree |
| Delivery | On our shelf and ready to go out today. |
Description
The compact Damper Actuator designed for HVAC applications controlling air and fire dampers, disc valves, and air-flow volume controllers-suitable for dampers up to 2 sq.m.
Features
- Power consumption (running): 2.5W
- Power consumption (holding): 0.6W
- Power Consumption For Wire Sizing: 5.5VA
- Connection Supply Control: Cable 1 m, 3x 0.75 sq.mm
- Connection Auxilary Switch: Cable 1 m, 3x 0.75 sq.mm
- Manual override: With push-button, can be locked
- Enclosure Type: UL Enclosure Type 2
- No external limit switches needed: Automatic motor stop at end position
- Simple direct mounting: Universal clamp and anti-rotation strap included
- Auxiliary switch flexibility: Adjustable for signaling dampers' positions
Certifications & Standards
| Ingress Protection | IP54 |
