Honeywell Fluorine Refrigerant Gas, Genetron R-134A, HFC

Genetron 134a (HFC-134a) has been developed by Honeywell to serve as one of the key substitutes for CFCs and HCFCs. Genetron 134a is a long-term, environmentally safer, non-ozone depleting substitute. As a refrigerant, it possesses similar energy efficiency and capacity characteristics as R-12 and has an intrinsically low toxicity. Genetron® 134a is the refrigerant of choice in automobile air-conditioning. It may be used in residential and commercial refrigeration, as well as commercial, and industrial air-conditioning.

Molecular weight: 102.03

Critical volume I (m3/kg): 0.002

Critical density I (kg/m3): 511.9

Vapour density at boiling point (kg/m3): 5.26

Liquid density III (kg/m3): 1207.0

Liquid heat capacity III (kJ/kg· Deg.K): 1.425

Vapour heat capacity III, IV (kJ/kg· Deg.K): 0.851

Heat of vaporization at boiling point (kJ/kg): 216.98

Vapour pressure III (kPa): 665.0

Liquid thermal conductivity III (W/m· Deg.K): 0.081

Vapour thermal conductivity III (W/m· Deg.K): 0.0138

Liquid viscosity III (?Pa·sec): 197.9

Vapour viscosity III (?Pa·sec): 11.8

Volatiles by volume: 100

Solubility of Genetron® 134a in water (wt.%): 0.15

Solubility of water in Genetron® 134a (wt.%): 0.11

Auto ignition temperature ( Deg.C): 770
