Kawamura Street Lighting Control KSO-22010 is Photo-Electric Sensor of Out-Door Type 220V 10A.
- Automatic Day-Light Switch.
- Voltage AC220V, Frequency 50-60Hz, Load Current 10A.
- Ambient Temp -20 to 50 Deg. C.
- Out-Door Type 220V 10A.
- Power Consumption Max. 2.0 W.
- Operating Illumination: Turn-ON Less 30Lux and Turn-OFF Less 150Lux.
- At using for Mercury or Fluorescent lamp, connect the Control unit in the primary side of stabilizer, Connect Red-lead wire first for safety.
- For Incandescent lamp, connect Black-lead wire and White-lead (common) to power source, Red-lead wire and White-lead to lamp load.
