Schneider Electric
Schneider Electric NSX100B Molded Case Circuit Breaker, C10B6TM080, ComPacT, 4P, 25 kA, 415VAC, 80A
SV Code: 472338267635Model No.: C10B6TM080
50/60 Hz80 A800 VAC25 kA at 415VAC140 mm
AED 626.00/ Piece
In stock — ships today
On our shelf and ready to go out today.
Return or exchange within 30 days of delivery.Sign in to see your account price and place orders.
Key features
- Neutral Position: Left
- Network Type: AC
- Utilisation Category: Category A
- Performance Level: B 25 kA 415VAC
- Trip unit name: TM-D
- Circuit Breaker Mounting Mode: Fixed
Fast delivery Genuine & warranty Bulk quotes
Specifications
| SV Code | 472338267635 |
| Brand | Schneider Electric |
| Category | Molded Case Circuit Breakers |
| Unit | Piece |
| Frequency | 50/60 Hz |
| Current | 80 A |
| Insulation Voltage | 800 VAC |
| Breaking Capacity | 25 kA at 415VAC |
| Width | 140 mm |
| Height | 161 mm |
| Depth | 86 mm |
| Colour | Black |
| Operating Temp | -25 to 70 Deg.C |
| Number of Poles | 4P |
| Storage Temperature | -50 to 85 Deg.C |
| Relative Humidity | 0-95% |
| Control Type | Toggle |
| Pollution Degree | 3 |
| Operating Altitude | 0-5000 Mtr |
| IK Rating | IK07 |
| Pitch | 35 mm |
| Trip Type | Thermal-magnetic |
| Brand Origin (not manufacture) | France |
| Delivery | On our shelf and ready to go out today. |
Description
This ComPacT NSX100B is a complete 4P 3d fixed circuit breaker designed to optimize space and breaking capacity. It is an optimal choice for all standard and specific applications. The breaking capacity (Icu) is 25kA rms at 415VAC 50/60Hz. The operational voltage is 690VAC 50/60Hz. This product embeds a 80A rating thermal-magnetic trip unit (TMD). TMD trip unit provides an adjustable thermal overload protection and a fixed magnetic protection.
Features
- Neutral Position: Left
- Network Type: AC
- Utilisation Category: Category A
- Performance Level: B 25 kA 415VAC
- Trip unit name: TM-D
- Circuit Breaker Mounting Mode: Fixed
- Rated Impulse Withstand Voltage: 8 kV
- Mechanical Durability: 50000 Cycles
- Power Dissipation per Pole: 8.77W
- Mounting Support: Backplate
- Mounting Position: Horizontal and Vertical Flat on the back
- Number of Slots for Electrical Auxiliaries: 5
- Overvoltage Category: Class II
Certifications & Standards
| Standards | EN/IEC 60947 |
| Ingress Protection | IP40 |
| Certification | CCC, EAC, Marine Listed |
