Flir
Flir Thermal Imaging Camera, A320, 320 x 240p, 9Hz, -20 to 350 Deg.C
SV Code: 252991688714Model No.: A320Article Number: 48201-1201
18 mmBlackAluminium25 micron9 Hz
AED 61,776.00/ Piece
Out of stock
Return or exchange within 30 days of delivery.Sign in to see your account price and place orders.
Key features
- Screening: difference temperature alarm with a dynamic updated reference temperature (visualized by the isotherm)
- Built-in extensive analysis functionality
- Extensive alarm functionality, as a function of analysis and more
- On schedule: file sending (FTP) or e-mail (SMTP) of analysis results or images
- On alarms: file sending (FTP) or e-mail (SMTP) of analysis results or images
- MPEG-4 streaming
Fast delivery Genuine & warranty Bulk quotes
This model family (2 options)
| Product | Price | Availability |
|---|---|---|
| Flir Thermal Imaging Camera, A320, 320 x 240p, 30Hz, -20 to 350 Deg.C | AED 49,897.00 | Quote |
| Flir Thermal Imaging Camera, A320, 320 x 240p, 9Hz, -20 to 350 Deg.C viewing | AED 61,776.00 | Quote |
Specifications
| SV Code | 252991688714 |
| Brand | Flir |
| Category | Thermal Imager |
| Unit | Piece |
| Temperature Range | -20 to 350 Deg.C |
| Spectral Range | 7.5-13 micron |
| Focal Length | 18 mm |
| Colour | Black |
| Housing Material | Aluminium |
| Operating Temperature | -15 to 50 Deg.C |
| Storage Temperature | -40 to 70 Deg.C |
| Pitch | 25 micron |
| Frame Rate | 9 Hz |
| Field of View | 25 x 18.8 Degree |
| Maximum Aperture | F/1.3 |
| Minimum Focus Distance | 0.4 Mtr |
| Thermal Sensitivity | <0.05 Deg.C at 30 Deg.C (86 Deg.F)/50 mk |
| Digital Zoom | 1 to 8x Continuous, Digital, Interpolating |
| Detector Resolution | 320 x 240p |
| Detector Type | Focal plane array (FPA), Uncooled microbolometer |
| Brand Origin (not manufacture) | United States |
| Delivery | Not on the shelf right now; 7 working days to source and deliver. |
Description
The A320 (9 Hz) is a camera preconfigured to work in applications where you need to find temperature deviations in a population of people, utilizing difference temperature alarms with a dynamically updated reference temperature. The thermal imager provides accurate temperature measurement and features, such as analysis, alarm functionality and autonomous communication using standard protocols.
Features
- Screening: difference temperature alarm with a dynamic updated reference temperature (visualized by the isotherm)
- Built-in extensive analysis functionality
- Extensive alarm functionality, as a function of analysis and more
- On schedule: file sending (FTP) or e-mail (SMTP) of analysis results or images
- On alarms: file sending (FTP) or e-mail (SMTP) of analysis results or images
- MPEG-4 streaming
- Poe (Power over Ethernet)
- Built-in web server
- General purpose I/O
- Synchronization through SNTP
- Composite video output
- Multi-camera utility software: FLIR IP Config and FLIR IR Monitor included
- 16-bit 320 x 240 pixel images semi-real time, signal and temperature linear
- 100 Mbps Ethernet (100 m cable, wireless, fiber, etc.)
- Spatial Resolution: 1.36 mrad
